CR-203 Roll Wrapping Machine

CR203 Reel Wrapper is a machine designed for packing rolls of paper, non-woven fabrics, film and similar products made in rolls. It is ideal for reel axial wrapping-across the cylindrical diameter then along the longitudinal axis. CR203 is the ideal wrapper for reel type products to achieve dust and moisture proof and enhanced packing effects for transport and storage. Options: pneumatic reel ejection system, or fully automatic conveyorized reel wrapper.

CR203 Reel Wrapper is a machine designed for packing rolls of paper, non-woven fabrics, film and similar products made in rolls. It is ideal for reel axial wrapping-across the cylindrical diameter then along the longitudinal axis. CR203 is the ideal wrapper for reel type products to achieve dust and moisture proof and enhanced packing effects for transport and storage. Options: pneumatic reel ejection system, or fully automatic conveyorized reel wrapper.

*Powered pre-stretch film carriage, ratio 250%.

*Automatic wrapping according to pre-set parameters. Friendly user interface for setting wrap cycles and film tension.

*Auto height detection, turntable home position, forklift sockets for easy moving.

*Roller speed variable through an inverter.

*Dual limit switches on top & bottom to provide better safety protections.

01.Wrapping size :                      L(500-1500)mm, W(500-1600)mm.

02 Packing Speed:                     20-40 per hour.

03.Loading Weight :                   2000kg.

05. Turntable Speed:                 0-150rpm, speed variable, turntable soft start & soft sotp.

06. Turntable Height:                  460mm.(Ejection Type:530)

07. Carriage Speed:                   3m/min.

08. Control system:                    PLC.

09. Working Mode:                      automatic

10. Power:                                    3PH280VAC, 50/60Hz,20A, 3.4Kw.

11. Dimensions:                         2950 X 1800 X 2582mm.

12. Machine Weight:                   1100kg.


Please contact or email us for need a quotation and detail information
