CHM 50-50-12 AUTOMATIC BOTTLE WASHING-FILLING-CAPPING MACHINE

Mesin Pencuci Pengisi Penutup Botol dengan Model Rotary Monoblock.Memiliki 50 nosel pencucian, 50 nosel pengisian, dan 12 capper head (kepala penutup).Bekerja dengan kecepatan 15.000 s/d 18.000 botol per jam.

Washing Nozzle : 50
Filling Nozzle : 50
Cpping Head : 12
Power : 380V/50Hz, 10KW
Capacity : 15.000-18.000 bottles/hour
Filling Range : 200-3000ml
Filling Precision : +-5ml
Dimension : 4500x2500x2500mm
Weight : 10.000kg
Suitable Cap Shape : Plastic Screw Cap
The size of bottle : Diameter 50-100mm, height 150-320mm
Gas Consumption : 0,5m3/min
Gas Pressure : 0,4Mpa
Water Pressure of Washing Bottle : 0,18Mpa
Water of Washing Bottle : 4000kg/hour

Touch Screen Panel : WEINVIEW / DELTA - Taiwan

PLC : MITSUBISHI / OMRON - Japan

mesin merek carmel
